2004-06 LJ 3-Link Front & Double Triangulated 4-Link Rear Long Arm Upgrade

2004-06 LJ 3-Link Front/4-Link Rear Double Triangulated Long Arm Upgrade

We wanted to change the LJ suspension game. Our kit is a true double triangulated rear to minimize rear steer. We offer stock length, 4" and 7" rear stretch options. We made our skid plate so that it can be removed without holding up the transmission.

Kit includes:
Weld-in side brackets with integrated front link mounts
Third link mount for axle side
Bolt-in rear crossmember for double triangulation
Truss top 4-link mounts (truss not included)
Axle side lower control arm mounts
Bolt-in transmission mount cross member
(1) Skid Plate 1/4" laser cut and CNC smooth bottom
(4) 2" 7075 T6 aluminum lower links w/Rock Jock narrow joints at both ends
(1) 1.75" 7075 T6 aluminum upper link w/Rock Jock narrow joints at both ends
(2) 2" solid 7075 T6 aluminum upper links with narrow Rock Jock Johnny Joints
Includes all grade 8/10.9 hardware

PLEASE NOTE:
This kit requires:
Welding brackets to frame and axles
Factory fuel tank must be relocated for stretch kits
Rear axle to have a truss (not included)
Evaporative canister will need to be relocated with stretch kits
Exhaust will need to be customized
